| Processing length | 200-1500mm (2m and 2.5m specifications can be customized) | ||
| Material diameter | 20-300mm | ||
| Minimum setting unit | 0.01cm | ||
| Rotating spindle | 4KW servo spindle | ||
| Engraving spindle power | 3.5kw air-cooled spindle (used for slotting and engraving) | ||
| Spindle speed | 0-3000r/min | ||
| Stepper drive, motor | Research and control YOKA 2811MA, 450B450C motor | ||
| Operating Voltage | 380V 3PH AC power | ||
| Working frequency | 50Hz | ||
| Control System | RichAuto DSP control system | ||
| Pneumatic pressure | 0.6-0.8Mpa | ||
