| Moel No. | LR-1212 5Ex | LR-1224 5Ex | Customized | ||
| Traveling size | 1720*1820*750mm | 1720*3040*750mm | √ | ||
| Working size | 1220*1220*500mm | 1220*2440*500mm | √ | ||
| Table size | 1230*1220mm | 1230*2440mm | √ | ||
| B/C Axis | B:±185° C:±320° | × | |||
| Max positioning speed | B:10000°/' C:11500°/' | × | |||
| Max work speed | B:4500°/' C:5500°/' | × | |||
| Axes positioning precision | 1 arcmin | × | |||
| Transmission | X/Y Rack and Pinion Drive, Z Ball Screw Drive | × | |||
| Spindle Power | 8.5/12KW(HSD/HITECO) | × | |||
| Traveling Speed | 60/60/20 m/min | × | |||
| Working Speed | 20 m/min | × | |||
| Tool magazine | Carousel 8/12 Slots | √ | |||
| Driving System | Yaskawa | √ | |||
| Moel No. | LR-1212 5Ex | LR-1224 5Ex | ||
| Traveling size | 67.7*71.6*29.5inch | 67.7*119.7*29.5inch | ||
| Working size | 48*48*19.7inch | 48*96*19.7inch | ||
| Table size | 48.4*48inch | 48.4*96inch | ||
| B/C Axis | B:±185° C:±320° | |||
| Max positioning speed | B:10000°/' C:11500°/' | |||
| Max work speed | B:4500°/' C:5500°/' | |||
| Axes positioning precision | 1 arcmin | |||
| Transmission | X/Y Rack and Pinion Drive, Z Ball Screw Drive | |||
| Spindle Power | 7.5/12KW(HSD/HITECO) | |||
| Traveling Speed | 196.8/196.8/65.6 ft/min | |||
| Working Speed | 65.6 ft/min | |||
| Tool magazine | Carousel 8/12 Slots | |||
| Driving System | Yaskawa | |||
