Linear Disc ATC CNC router with drum type ATC kit has no need to change tools manually during machining, is used for decorations, musical instruments, wood crafts, wood furniture, wood door making, cabinet making, windows, tables, etc. Now the best linear ATC wood CNC router for sale at affordable price. |
Availability: | |
---|---|
Quantity: | |
TECHNICAL PARAMETERS
Moel No. | LR-1325AE | LR-1530AE | LR-2040AE | Customized |
Working size | 1300*2500mm | 1500*3000mm | 2000*4000mm | √ |
Z-axis clearance | 200mm | √ | ||
Repeatability | ±0.03mm | × | ||
Drive system X and Y-axis | Helical rack and pinon | × | ||
Drive system Z-axis | ball screw | × | ||
Guide rails | 20/25mm linear ball-bearing profile rails(HIWIN/PMI/THK) | √ | ||
Motor & drive | YASKAWA(DELTA/FUJI)servo motor | √ | ||
Spindle | 7.5KW/9KW/12KW air cooling | √ |
Choose Atc Machine
High power motorized spindle
Motor drive
Automatic lubrication system
Automatic tool calibration pad
Smart control system
TECHNICAL PARAMETERS
Moel No. | LR-1325AE | LR-1530AE | LR-2040AE | Customized |
Working size | 1300*2500mm | 1500*3000mm | 2000*4000mm | √ |
Z-axis clearance | 200mm | √ | ||
Repeatability | ±0.03mm | × | ||
Drive system X and Y-axis | Helical rack and pinon | × | ||
Drive system Z-axis | ball screw | × | ||
Guide rails | 20/25mm linear ball-bearing profile rails(HIWIN/PMI/THK) | √ | ||
Motor & drive | YASKAWA(DELTA/FUJI)servo motor | √ | ||
Spindle | 7.5KW/9KW/12KW air cooling | √ |
Choose Atc Machine
High power motorized spindle
Motor drive
Automatic lubrication system
Automatic tool calibration pad
Smart control system
