Dust collector
3/4/5.5KW double bag high power vacuum cleaner,Make your working environment cleaner and safer
Vauum pump
air / oil-less vacuum pump . Faster and stronger fixation of materials to be processed
Moel No. | LR-1325AE | LR-1530AE | LR-2040AE | Customized |
Working size | 1300*2500mm | 1500*3000mm | 2000*4000mm | √ |
Z-axis clearance | 200mm | √ | ||
Repeatability | ±0.03mm | × | ||
Drive system X and Y-axis | Helical rack and pinon | × | ||
Drive system Z-axis | ball screw | × | ||
Guide rails | 20/25mm linear ball-bearing profile rails(HIWIN/PMI/THK) | √ | ||
Motor & drive | YASKAWA(DELTA/FUJI)servo motor | √ | ||
Spindle | 7.5KW/9KW/12KW air cooling | √ |
Moel No. | LR-1325AE | LR-1530AE | LR-2040AE | Customized |
Working size | 51*98inch | 59*118inch | 79*157inch | √ |
Z-axis clearance | 7.9inch | √ | ||
Repeatability | ±0.001inch | × | ||
Drive system X and Y-axis | Helical rack and pinon | × | ||
Drive system Z-axis | ball screw | × | ||
Guide rails | 0.8/1inch linear ball-bearing profile rails(HIWIN/PMI/THK) | √ | ||
Motor & drive | YASKAWA(DELTA/FUJI)servo motor | √ | ||
Spindle | 7.5KW/9KW/12KW air cooling | √ |
