| Moel No. | LR-13254Ex | LR-15304Ex | LR-20404Ex | Customized |
| Working size | 1300*2500mm | 1500*3000mm | 2000*4000mm | √ |
| Z-axis clearance | 300mm/400mm/500mm | √ | ||
| Repeatability | ±0.03mm | × | ||
| Drive system X and Y-axis | Helical rack and pinon | × | ||
| Drive system Z-axis | ball screw | × | ||
| Guide rails | 20/25mm linear ball-bearing profile rails（HIWIN/PMI/THK） | √ | ||
| Motor & drive | YASKAWA(DELTA/FUJI)servo motor | √ | ||
| Spindle | 4.5KW/6KW/9KW manual（ATC）all available | √ | ||
| Moel No. | LR-1325AEx | LR-1530AEx | LR-2040AEx | Customized |
| Working size | 51*98inch | 59*118inch | 79*157inch | √ |
| Z-axis clearance | 11.8inch/15.7inch/19.7inch/ | √ | ||
| Repeatability | ±0.001inch | × | ||
| Drive system X and Y-axis | Helical rack and pinon | × | ||
| Drive system Z-axis | ball screw | × | ||
| Guide rails | 0.8/1inch linear ball-bearing profile rails（HIWIN/PMI/THK） | √ | ||
| Motor & drive | YASKAWA(DELTA/FUJI)servo motor | √ | ||
| Spindle | 4.5KW/6KW/9KW manual（ATC）all available | √ | ||
